CNC Lathe Machine Feature
- Overall bed structure, high machining accuracy, smooth chip removal, suitable for high-precision machining
- Fast tool change speed and high positioning accuracy
- The machine tool adopts full protection design, which is pleasant, safe and reliable
| Technical Parameters | Unit | CK6180 |
| Max.swing over bed | mm | 800 |
| Max.swing over cross slide | mm | 450 |
| Spindle hole | mm | 105 |
| X-axis travel | mm | 420 |
| Z-axis travel | mm | 1500/2000/3000 |
| Tailstock sleeve stroke | mm | 250 |
| Tailstock sleeve diameter | mm | 100 |
| Motor power | kw | 15 |
| Positioning accuracy | mm | 0.01 |
| Dimensions | mm | 3900*1900*2000 |
| Machine weight | kg | 4500 |
